ELECTRICAL CHARACTERISTICS :

Conductor Resistance: Max9.38Ωs/100m
Max Attenuation: 1MHz 2.6db/100m
4MHz 5.6db/100m
8MHz 8.5db/100m
10MHz 9.7db/100m
16MHz 13.1db/100m
Mutual Capacitance: 6.6nF/100m 1KHz
Capacitance Unbalance: 330pF/100m 1KHz
Characteristic lmpedance: 100+/-15Ωs



CFS5E20025	UTP Cat 5e,25P,CMR,24AWG,305m
CFS5E20050	UTP Cat 5e,50P,CMR,24AWG,305m
CFS5E20100	UTP Cat 5e,100P,CMR,24AWG,305m
CT310025	UTP Cat 3,25P, CMR,24AWG,305m
CT310050	UTP Cat 3,50P, CMR,24AWG,305m
CT310100	UTP Cat 3,100P, CMR,24AWG,305m
